Kontron Showcased its 5G Ready KBox R-101 Solution at InnoTrans
Author : Radio China    Time : 2022-09-27    Source : www.radiochina.info
share:

Kontron, a leading global provider of IoT/Embedded Computing Technology (ECT), presented the KBox R-101, a new control and communication platform in Box-PC format for demanding tasks, at InnoTrans 2022 in Berlin. Kontron's new compact central computer is based on a fanless, passively cooled and IP54-compliant system solution with established and industry-approved mechanical and electronic components. The system as well as all external interfaces are specifically designed for use within railroad and public transport applications as well as harsh industrial environments and are therefore EN 50155-compliant.


The new KBox R-101 enables multiple radio modules to be operated simultaneously for WLAN, 5G/LTE, GSM, LPWA as well as GNSS and ensures, for example, the best possible radio connection by using a maximum of eight provider profiles - by automatically switching to the most suitable mobile network.

Based on the 11th Gen Intel® Core™ i7-1185GRE processor or the Intel Atom® processor x6212RE as well as a memory expansion of max. 32 GB, the new platform supports OEM manufacturers and system integrators in building high-performance and reliable system solutions.


On the front, the KBox R-101 has three M-12 x-coded Gigabit Ethernet interfaces, two serial I/Os and a USB-C interface. In addition, there are six knockouts for antenna connections (SMA, QMA) as well as seven LEDs that can be used for specific applications and a power LED.


By means of the USB-C service interface, the operator is enabled to realize a DisplayPort- and a USB 3.1-based connection as well as a power supply with up to 10W for e.g. touch panels via only one line; this facilitates debugging as well as commissioning.


Behind the IP54-protected cover on the rear of the system, there are also two USB 2.0 ports, a DisplayPort and a CFexpress interface that supports transfer rates of up to 2Gb/s, as well as two micro-SIM sockets. The wide-range power supply supports nominal voltages from 24V DC to 110V DC, furthermore it offers a hold-up time according to class S2 and a controllable ignition input.


The system is designed for operation in the extended temperature range between -40 °C and +70 °C (+85 °C for a maximum of 10 minutes) and completely foregoes moving parts.


Depending on individual requirements, the KBox R-101 can be expanded to include additional interfaces and on-board modules, which increases investment security because future performance and interface expansions are also guaranteed.


Due to the approval according to EN 50155, the compact system is certified for mobile use as a rolling stock or for wayside monitoring in railroads and public transport.
